Patient Monitor PM-RB9000N

Product Overview

The Wincom Patient Monitor PM-RB9000N is a portable bedside monitor tracking six parameters — ECG, heart rate, SpO2, NIBP, respiration and temperature — on a 12-inch colour TFT display supporting up to 12 waveforms. The white chassis carries a row of front function buttons with a blue rotary dial, side-stacked sensor ports and a high-contrast multi-colour monitoring screen showing ECG and respiration waveforms alongside HR, NIBP, dual temperature and SpO2 numerics. At 5 kg it moves easily between bedsides and transport situations. KRIMS Meditech Solutions Limited supplies this equipment with professional installation, commissioning, clinical training and after-sales support by factory-trained biomedical engineers.

Applications

Continuous multi-parameter vital signs monitoring for adult, paediatric and neonatal patients in ICUs, wards, emergency departments and during intra-hospital transport.

Clinical Benefits

Six vital parameters on a 12-inch colour display with up to 12 simultaneous waveforms give clinicians a complete bedside picture in a 5 kg portable unit.

Key Features

Six parameters: ECG, HR, SpO2, NIBP, RESP, TEMP; 12-inch colour TFT display; up to 12 waveforms; front function buttons with blue rotary dial; side-stacked sensor ports; 5 kg portable bedside format.

Technical Specifications

Art. No.: PM-RB9000N | Parameters: ECG, HR, SpO2, NIBP, RESP, TEMP (six parameters) | Display: 12" colour TFT, up to 12 waveforms | Weight: 5 kg | Format: portable bedside monitor — per Wincom Company Ltd. listings and catalogue

Accessories

Included

ECG leads, SpO2 sensor, NIBP cuff and temperature probe as supplied by manufacturer.

Installation Requirements

Standard mains power; patient sensor sets and mounting as per bedside configuration.
