Volumetric Infusion Pump BYS-820

Product Overview

The BYOND (BEYOND Medical Devices Co., Ltd.) Volumetric Infusion Pump BYS-820 delivers accurately controlled IV infusions via a peristaltic pumping mechanism. The white vertical unit carries Power, Alarm and Door indicators, a large LED total-infusion-volume display with an LCD showing rate, time and pre-set volume, and a membrane keypad with Start/Stop/Purge/Silence and Shift/Select controls. Safety systems include an ultrasonic bubble detector at the top of the tube channel, an in-line pressure sensor with selectable occlusion levels — low 300 mmHg ±100 mmHg (40.7 kPa ±13.3 kPa) and medium 500 mmHg ±100 mmHg (66.7 kPa ±13.3 kPa) — a liquid-retaining clamp, tube-type indicators for compatible IV sets and a unique audible alarm system. A door with squeezing board clamps the infusion set against the peristaltic sheet. KRIMS Meditech Solutions Limited supplies this equipment with professional installation, commissioning, clinical training and after-sales support by factory-trained engineers.

Applications

Accurate volumetric IV infusion — fluids, medications and nutrition — in wards, ICUs, operating theatres, emergency and paediatric care settings.

Clinical Benefits

Bubble detection, in-line pressure sensing with graded occlusion limits and audible alarms protect patients while peristaltic control maintains delivery accuracy.

Key Features

Volumetric peristaltic infusion; LED total-infusion-volume display with LCD rate/time/pre-set volume readout; ultrasonic bubble detector; in-line pressure sensor with selectable occlusion levels; low occlusion 300 mmHg ±100 mmHg (40.7 kPa ±13.3 kPa), medium occlusion 500 mmHg ±100 mmHg (66.7 kPa ±13.3 kPa); unique audible alarm; Start/Stop/Purge/Silence membrane keypad; tube-type indicator lights; liquid-retaining clamp; door with squeezing board.

Technical Specifications

Model: BYS-820 | Type: volumetric infusion pump (peristaltic) | Occlusion pressure: low 300 mmHg ±100 mmHg (40.7 kPa ±13.3 kPa); medium 500 mmHg ±100 mmHg (66.7 kPa ±13.3 kPa) | Indicators: Power, Alarm, Door; total infusion volume display; tube type indicator | Alarms: unique audible alarm system | Keypad: Shift, Up, Select, Down, Silence, Stop, Start, Purge | Compatibility: standard IV infusion sets per tube-type indicator — per BYOND operating documentation and distributor listings

Accessories

Included

IV pole clamp and power adapter as supplied by manufacturer.

Optional

Compatible IV infusion sets per indicated tube types; BYS-820D variant per manufacturer documentation.

Installation Requirements

IV pole or bedside mounting; mains power; infusion set loading and occlusion-limit configuration during commissioning.
