1 / 5Fluorescent Quantitative PCR Thermal Cycler F30-96A (BIOER)
Manufacturer: Hangzhou Bioer Technology Co., Ltd (BIOER) · Origin: China
SKU: KES-PCR-BIOER-F3096A · Model: F30-96A
BIOER F30-96A real-time fluorescent quantitative PCR system with Peltier thermoelectric temperature control and PMT fluorescence detection, 100–240 V, 600 W.
Product Overview
The BIOER (Hangzhou Bioer Technology Co., Ltd) Fluorescent Quantitative PCR Thermal Cycler F30-96A is a benchtop real-time PCR instrument for quantitative nucleic acid analysis. The nameplate-verified unit combines Peltier thermoelectric temperature control — indicated on the front panel — with PMT (photomultiplier tube) fluorescence detection and Bluetooth connectivity, in a two-tone silver and charcoal chassis with louvered cooling. Nameplate data confirms 100–240 V, 50/60 Hz, 600 W power input, IVD classification and Zhejiang medical device registration; the model designation 96A indicates the 96-position sample format. Detection-channel configuration and temperature-range specifications are confirmed with manufacturer documentation at quotation stage. KRIMS Meditech Solutions Limited supplies this equipment with professional installation, commissioning, application training and after-sales support by factory-trained engineers.
Applications
Real-time fluorescent quantitative PCR for clinical molecular diagnostics, pathogen detection and research quantification in hospital, public health and research laboratories.
Clinical Benefits
Peltier-controlled thermal cycling with PMT fluorescence detection supports sensitive quantitative nucleic acid testing at the bench.
Key Features
Peltier thermoelectric temperature control; PMT (photomultiplier tube) fluorescence detection; Bluetooth connectivity; 96-position sample format (model designation 96A); two-tone silver/charcoal benchtop chassis with louvered cooling; IVD classified; 100–240 V 50/60 Hz 600 W.
Technical Specifications
Product model per detailed nameplate re-inspection: F-96A (杭州博日科技有限公司 Hangzhou Bioer Technology Co., Ltd, www.bioer.com.cn; unit serial FY9008-020107, manufactured 2015.01) — NOTE: initial nameplate reading recorded as F30-96A; MODEL DESIGNATION VERIFICATION REQUIRED against the physical unit | Power input: 100–240 V~, 50/60 Hz, 800 W per detailed nameplate reading (fuse 250 V 8 A; initial reading recorded 600 W — power rating pending manufacturer confirmation) | Temperature control: Peltier thermoelectric | Detection: PMT (photomultiplier tube) | Connectivity: Bluetooth; DB-15 comm connector on rear panel; three rear cooling fans | Classification: IVD | Protection: Class I equipment, IP20 | Registration: per nameplate 证字2011第240019号 (initial reading 浙械注准2011第2400159号 — pending confirmation) | Operating ambient temperature: 10 °C–30 °C | Installation: exhaust vents ≥30 cm from walls or other obstructions | Sample format: 96-position per model designation | Detection channels and temperature range: manufacturer documentation pending verification — per unit nameplate and warning labels
Installation Requirements
Bench placement indoors at 10–30 °C with ≥30 cm clearance at the exhaust vents, stable mains power and recommended UPS.
